Chat Box


The Chat Box is able to read and write messages to the in-game chat. You can send messages to just one player or to everyone.

Hint

If you prefix your message with a $ the message will not be sent to the global chat but it will still fire the chat event.
Example:
$this message is hidden!

---

Peripheral Name	Interfaces with	Has events	Introduced in
chat_box	Game Chat	Yes	0.1b

---

Events

chat

Fires when a chat message appears within a chatbox's detection range.

Values:

1. uuid: string Message sender's UUID. nil if triggered from a /say command
2. name: string Message sender's name. [say] if triggered from a /say command
3. message: string The chat message
4. isHidden: boolean Whether or not the message is privately sent to chatboxes
5. encodedUtf8Message: string The encoded chat message from utf8

local event, uuid, username, message, isHidden = os.pullEvent("chat")
print("The 'chat' event was fired with the username " .. username .. " and the message " .. message)

Info

The chat event will fire when a chatbox has been connected to a computer. You don't have to .wrap() or .find() the peripheral (unless you intend to send messages).

---

Functions

sendMessage

sendMessage(message: string, options: table | nil) -> true | nil, string

Broadcasts a message to the global chat or if range is specified it is sent to all players in the range.
Returns true if the message is successfully sent, or nil and an error message if it fails.

options format:

{
    player: string | nil = message will only send to the player when specified
    utf8: boolean | nil = if strings and message should be treated as encoded utf8
    range: number | nil = the broadcast range
    prefix: string | nil = change the text that appears inside the brackets at the start of a message. Defaults to "AP".
    brackets: string | nil = used around the prefix. Must specify a two length string like "[]", "()", "<>", ...
    bracketColor: string | nil = specifies the color to use for the brackets, must be in the [MOTD code format](https://www.digminecraft.com/lists/color_list_pc.php).
}

Returns true if the message is successfully sent, or nil and an error message if it fails.

local chatBox = peripheral.find("chat_box")

chatBox.sendMessage("Hello world!") -- Sends "[AP] Hello world!" in chat
sleep(1) -- We must account for the cooldown between messages, this is to prevent spam
chatBox.sendMessage("I am dave", {prefix="Dave"}) -- Sends "[Dave] I am dave"
sleep(1)

-- Sends message "Welcome!" with cyan <> brackets around "<Box>"
-- to players within 30 blocks of the chat box
chatBox.sendMessage("Welcome!", {prefix="Box", brackets="<>", bracketColor="&b", range=30})

chatBox.sendMessage("Hello there.", {player="Player123"}) -- Sends "[AP] Hello there." to Player123 in chat

Tip

Just like the bracketColor argument you can add colors to the message and prefix arguments using the same MOTD color code format.
Since CC doesn't accept non-ascii charactor §, you should replace it with &.
If you want to send colored message but not only colored brackets, please use sendFormattedMessage() instead.

---

sendFormattedMessage

sendFormattedMessage(json: string, options: table | nil) -> true | nil, string

This function is fundamentally the same as sendMessage() except it takes a json text component as the first parameter.
Find out more information on how the text component format works on the minecraft wiki. You can generate the json at minecraft.tools.

local chatBox = peripheral.find("chat_box")

local message = {
    {text = "Click "},
    {
        text = "here",
        underlined = true,
        color = "aqua",
        clickEvent = {
            action = "open_url",
            value = "https://advancedperipherals.madefor.cc/"
        }
    },
    {text = " for the AP "},
    {text = "documentation", color = "red"},
    {text = "!"}
}

local json = textutils.serialiseJSON(message)

chatBox.sendFormattedMessage(json)

---

sendToast

sendToast(options: table) -> true | nil, string

Sends a toast to the specified player. The design of the toast is the classic notification design. It's planned to add a custom rendered design in the future.

options format:

{
    message: string = the message in the toast
    title: string = the title of the toast
    player: string = player's name or uuid

    utf8: boolean | nil = if strings should be treated as encoded utf8
    prefix: string | nil = change the text that appears inside the brackets at the start of a message. Defaults to "AP".
    brackets: string | nil = used around the prefix
    bracketColor: string | nil = specifies the color to use for the brackets
}

local chatBox = peripheral.find("chat_box")

chatBox.sendToastToPlayer({
    message = "I will chat box you",
    title = "Hello",
    player = "Dev",
    prefix = "&4&lBoxi",
    brackets = "()",
    bracketColor = "&c&l",
})

---

sendFormattedToast

sendFormattedToast(options: table) -> true | nil, string

This function is fundamentally the same as sendToast() except it takes a json text component for message, and title fields.
Find out more information on how the text component format works on the minecraft wiki. You can generate the json at minecraft.tools.

local chatBox = peripheral.find("chat_box")


local title = {
    { text = "Hello", color = "dark_purple"}
}

local message = {
    { text = "I will chat "},
    { text = "box ", color = "red"},
    { text = "you"}
}

local titleJson = textutils.serializeJSON(title)
local messageJson = textutils.serialiseJSON(message)

successful, error = chatBox.sendFormattedToast({
    message = messageJson,
    title = titleJson,
    player = "Dev",
    prefix = "&4&lBoxi",
    brackets = "()",
    bracketColor = "&c&l",
})

---

narrateMessage

narrateMessage(message: string, options: table | nil) -> true | nil, string

Narrate the message to players around.

Warning

Narration is based on individual player's system settings. People may hear different sounds and/or different speech speeds. The same word may also be pronounced differently, or may not be pronounced at all, depending on their system language.

options format:

{
    player: string | nil = message will only send to the player when specified
    utf8: boolean | nil = if strings should be treated as encoded utf8
    delay: boolean | nil = if the narrate message should queued after the previous narrations
}

local chatBox = peripheral.find("chat_box")

chatBox.narrateMessage("Hello world!")
chatBox.narrateMessage("Say hi to Dev only", {
    player = "Dev",
})

---

Changelog/Trivia

0.8
Added narrateMessage.
Merged sendMessageToPlayer variant to sendMessage by specific player option value.

1.19.2-0.7.33r/1.20.1-0.7.37r
Added sendToastToPlayer and sendFormattedToastToPlayer

0.7r
Added the uuid and isHidden parameter to the chat event. Also added the sendFormattedMessage function.

4.0b
Fixed the chat box so that is should now work in LAN worlds

0.1b
Added the chat box. This was the first feature of the mod.
