Overlay Module¶


The Overlay Module allows scripts render stuff on player's GUI.

Objects¶

All fields will have a getter and a setter, which is defined as getXxx and setXxx. For boolean fields, getter is defined as either isXxx or hasXxx.

OverlayObject¶

Field	Type	Default	Description
`enabled`	`boolean`	`true`	whether or not to render the object

type¶

getType() -> string

returns the object's type.

getId¶

getId() -> number

returns the object's integer ID.

RenderableObject¶

Based on OverlayObject

Field	Type	Default	Description
`opacity`	`number`	`1`	A decimal number that determines the transparency of the object, in range of `[0.0, 1.0]`
`color`	`number`	`-1`	An integer that determines the color of the object, in format of 0xRRGGBB. The default value `-1` is equivalent to `0xFFFFFF` in most cases.
`x`	`number`	`0`	A decimal number of the object's X position
`y`	`number`	`0`	A decimal number of the object's Y position
`z`	`number`	`0`	A decimal number of the object's Z position
`rotX`	`number`	`0`	A decimal number determine the degrees the object's rotation around the X-axis, in range of `[0, 360]`
`rotY`	`number`	`0`	A decimal number determine the degrees the object's rotation around the Y-axis, in range of `[0, 360]`
`rotZ`	`number`	`0`	A decimal number determine the degrees the object's rotation around the Z-axis, in range of `[0, 360]`

getPos¶

getPos() -> number, number, number

returns the object's x, y, z.

setPos¶

setPos(number, number, number) -> nil

sets the object's x, y, z.

CircleObject¶

Based on RenderableObject

Field	Type	Default	Description
`radius`	`number`	`0`	Integer of the circle's radius, in range of `[0, ∞)`
`filled`	`boolean`	`true`	If the circle should be filled
`pixelated`	`boolean`	`true`	If the circle should be pixelated
`borderWidth`	`number`	`4`	Integer of the circle's border width, in range of `[0, 32767]`
`segments`	`number`	`25`	Integer of the circle's segments, in range of `[0, 100]`

ItemObject¶

Based on RenderableObject

Field	Type	Default	Description
`item`	`string \| nil`	`nil`	The registry ID of the item to render

LineObject¶

Based on RenderableObject

Field	Type	Default	Description
`endX`	`number`	`0`	A decimal number of line's X end
`endY`	`number`	`0`	A decimal number of line's Y end
`pixelated`	`boolean`	`false`	If the line should be pixelated
`width`	`number`	`4`	Integer of the line's width, in range of `[0, 32767]`

getEndPos¶

getEndPos() -> number, number

returns the object's endX, endY.

setEndPos¶

setEndPos(number, number) -> nil

sets the object's endX, endY.

RectangleObject¶

Based on RenderableObject

Field	Type	Default	Description
`sizeX`	`number`	`0`	A decimal number of rectangle's X size, in range of `[0, ∞)`
`sizeY`	`number`	`0`	A decimal number of rectangle's Y size, in range of `[0, ∞)`

getSizes¶

getSizes() -> number, number

returns the object's sizeX, sizeY.

setSizes¶

setSizes(sizeX: number, sizeY: number) -> nil

sets the object's sizeX, sizeY.

TextObject¶

Based on RenderableObject

Field	Type	Default	Description
`content`	`string`	`""`	The text to render
`fontSize`	`number`	`1`	A decimal number represents the text's font size, in range of `[0.0, 128.0]`
`shadow`	`boolean`	`false`	Whether or not render a shadow for the text
`center`	`boolean`	`false`	If the text should be centered at its position

ThreeDimensionalObject¶

Based on RenderableObject

Field	Type	Default	Description
`relativePosition`	`boolean`	`false`	Should the object's position relative to the player's head
`relativeRotation`	`boolean`	`false`	Should the object's rotation relative to the player's head
`depthTest`	`boolean`	`true`	If the object should hide behind other objects
`culling`	`boolean`	`true`	If the object's hidden faces should not be seen

BoxObject¶

Based on ThreeDimensionalObject

Field	Type	Default	Description
`sizeX`	`number`	`0`	A decimal number of rectangle's X size, in range of `[0, ∞)`
`sizeY`	`number`	`0`	A decimal number of rectangle's Y size, in range of `[0, ∞)`
`sizeZ`	`number`	`0`	A decimal number of rectangle's Z size, in range of `[0, ∞)`

getSizes¶

getSizes() -> number, number, number

returns the object's sizeX, sizeY, sizeZ.

setSizes¶

setSizes(sizeX: number, sizeY: number, sizeZ: number) -> nil

sets the object's sizeX, sizeY, sizeZ.

BlockObject¶

Based on BoxObject

Field	Type	Default	Description
`block`	`string?`	`nil`	The registry ID of the block to render
`states`	`table`	default states of the block	The states of the block
`tintAll`	`boolean`	`false`	Make the `color` attribute affect the whole block, not only the tintable parts

If color is -1, the block will shown with its original color palettes.

SphereObject¶

Based on ThreeDimensionalObject

Field	Type	Default	Description
`sectors`	`number`	`16`	An integer in range of `[1, 1024]`
`stacks`	`number`	`16`	An integer in range of `[1, 1024]`
`radius`	`number`	`1`	A decimal number of the sphere's radius, in range of `(0, 128]`

TextureObject¶

Based on ThreeDimensionalObject

Field	Type	Default	Description
`sizeX`	`number`	`0`	A decimal number of texture's X size, in range of `[0, ∞)`
`sizeY`	`number`	`0`	A decimal number of texture's Y size, in range of `[0, ∞)`
`width`	`number`	`0`	Image X-axis pixels count in range of `[0, 4096)`
`height`	`number`	`0`	Image Y-axis pixels count in range of `[0, 4096)`

getSizes¶

getSizes() -> number, number

returns the texture's sizeX, sizeY.

setSizes¶

setSizes(sizeX: number, sizeY: number) -> nil

sets the texture's sizeX, sizeY.

getImageSize¶

getImageSize() -> number, number

returns the texture's width, height.

setImageSize¶

setImageSize(width: number, height: number) -> nil

sets the texture's width, height.

getPixel¶

getPixel(x: number, y: number) -> number

returns the texture's pixel at (x, y), in format of 0xAARRGGBB.

setPixel¶

setPixel(x: number, y: number, color: number) -> nil

sets the texture's pixel at (x, y), in format of 0xAARRGGBB.

getAllPixels¶

getAllPixels() -> table

returns the texture's all pixels as a 2D map that can be indexed by pixels[y][x].

getPixels¶

getPixels(minX: number, minY: number, width: number, height: number) -> table

returns the texture's sub-pixels in the range as a 2D map that can be indexed by pixels[y][x].

setPixels¶

setPixels(minX: number, minY: number, two_dim_data: table) -> nil
setPixels(minX: number, minY: number, width: number, height: number, one_dim_data: table) -> nil

sets the texture's sub-pixels in the range from a 2D map that can be indexed by pixels[y][x], or from a 1D map that can be indexed by pixels[(y - 1) * width + x]

load¶

load(data: string) -> nil

load texture from data (which is the image bytes). width and height will be set to the image's width and height afterwards.

Info

Supported image format may vary depends on the server.
Default supported formats may include bmp, gif, jpeg, png, tiff, wbmp.

TorusObject¶

Based on ThreeDimensionalObject

Field	Type	Default	Description
`sides`	`number`	`32`	An integer in range of `[1, 1024]`
`rings`	`number`	`16`	An integer in range of `[1, 1024]`
`minorRadius`	`number`	`0.1`	A decimal number of inner radius of the ring, in range of `(0, 128]`
`majorRadius`	`number`	`0.5`	A decimal number of outer radius of the ring, in range of `(0, 128]`

TriangleObject¶

Based on ThreeDimensionalObject

Note

Triangle objects only visible when the vertex is ordered in counter-clockwise.

Field	Type	Default	Description
`x1`	`number`	`0`	A decimal number of the first vertex's X position
`y1`	`number`	`0`	A decimal number of the first vertex's Y position
`z1`	`number`	`0`	A decimal number of the first vertex's Z position
`x2`	`number`	`0`	A decimal number of the second vertex's X position
`y2`	`number`	`0`	A decimal number of the second vertex's Y position
`z2`	`number`	`0`	A decimal number of the second vertex's Z position
`x3`	`number`	`0`	A decimal number of the third vertex's X position
`y3`	`number`	`0`	A decimal number of the third vertex's Y position
`z3`	`number`	`0`	A decimal number of the third vertex's Z position

getPos1¶

getPos1() -> number, number, number

returns the object's x1, y1, z1.

setPos1¶

setPos1(x1: number, y1: number, z1: number) -> nil

sets the object's x1, y1, z1.

getPos2¶

getPos2() -> number, number, number

returns the object's x2, y2, z2.

setPos2¶

setPos2(x2: number, y2: number, z2: number) -> nil

sets the object's x2, y2, z2.

getPos3¶

getPos3() -> number, number, number

returns the object's x3, y3, z3.

setPos3¶

setPos3(x3: number, y3: number, z3: number) -> nil

sets the object's x3, y3, z3.
